Additive manufacturing of thermoforming molds delivers performance, savings, and agility.
1,000+ shots
with no apparent wear
Up to 65%
Lead time reduction
Up to 88%
Raw material cost savings

Thermoforming molds faster and at a lower cost

Thermoforming companies and manufacturers that use thermoformed components in their production processes are facing severe pressure to speed up production, reduce waste, and bring down costs, while at the same time experiencing a shortage in specialized labor.

Additive manufacturing can deliver high performance molds that produce quality parts while drastically reducing lead times and labor costs compared to traditional methods. 3D Systems offers a range of 3D printing solutions for applications from small precise tools with fine features to large molds for thermoforming heavy gauge plastics.

ANALOG

vs.

DIGITAL

Calendar

2-12 Weeks Waiting for Mold Tooling

3D Object

3D Printed Patterns Overnight

Spinning Analog Clock

Time and Money Lost to Tooling

3D Cube with Arrows

Flexibility to Update Design at Any Time

DECREASE COST AND SHORTEN LEAD TIMES FOR LARGE THERMOFORMING MOLDS

With EXT Titan Pellet extrusion additive manufacturing (AM) technology, 3D Systems customer Duo Form

  • decreases costs,
  • shortens lead times and
  • has become more agile

when producing molds and tools for heavy gauge thermoforming and vacuum forming processes.

Learn More - Duo Form Case Study
Duo Form Mold Worker

Solutions for 3D Printing Thermoforming Molds

  • Fast Validation

    Total lead times for cast ceramic and machined aluminum molds, as well as machined or hand-crafted prototyping tools, can be as long as 16 weeks. Validate forms faster by 3D printing thermoforming molds in hours or days, dependent on the size. Additive manufacturing also gives companies the agility to respond quickly to a customers’ design changes and even to produce representative prototypes of the final part.

  • Thermoforming Mold

  • Same mold for final production

    With 3D Systems’ additive manufacturing technologies like EXT pellet extrusion, stereolithography (SLA), selective laser sintering (SLS), and multi-jet printing (MJP), the same mold that is used during the validation process can be used for production, compounding the time and cost savings. 3D Systems thermoforming customers report pulling thousands of shots from 3D printed molds with little to no signs of wear or degradation of performance.

  • Same mold for final production

  • Cost-effective large thermoforming molds

    Large thermoforming molds often come with especially long lead times and high costs when produced with traditional methods. EXT pellet-extrusion 3D printing, on the other hand, enables the use of highly functional thermoforming mold materials at the lowest possible cost with lead times measured in days instead of weeks.

  • large thermoforming molds

Why Thermoforming with 3D Systems Additive Manufacturing Solutions

Dependent on the additive manufacturing technology and print material chosen, the following benefits versus conventional manufacturing are realized:

  • ADDITIVE

    Fast tool production – within hours or days

    Agility to quickly respond to design changes with little added cost

    Use validated prototype tool for production


    Minimal to no vacuum hole drilling required

    Reduced need for skilled labor in the mold production process

    Value Add: Use the 3D printer to produce representative prototypes of formed parts

  • CONVENTIONAL

    Lead times often between 1 and 16 weeks

    Design changes can be costly and time intensive to implement

    Conventional prototyping and bridge tools often degenerate due to low-quality material

    Drilling of vacuum holes required

    Pattern and mold production require many hours of skilled labor

    N/A

Choosing the right 3D Systems AM technology for your thermoforming application is an important first step.


EXT
SLA
Part Size
Medium to LargeSmall to Medium
Sheet Gauge
Medium Gauge <3mm (1/8”) with machining
Heavy Gauge >3mm (1/8”) with light sanding		Thin to Medium Gauge
Up to 3mm (1/8”)
Detail
Variable – Medium to CoarseFine
Printed Mold Surface Finish
Variable – Very Good to Coarse*
*In-situ or post machining can be used to smooth the mold surface		Excellent (SLA) to very good (MJP)
Recommended materials
GF PC, CF PC, CF ABSAccura materials (SLA), VisiJet M2S-HT250 (MJP)
Porosity
Inherent and controllable + drilled as-neededDesigned-in or drilled

3D Systems Printers and Materials for Thermoforming Molds

  • 3D Systems EXT Titan Pellet 1070 Printer

    EXT Titan Pellet extrusion 3D printers for cost-effective, large-format thermoforming molds for medium to heavy gauge sheets

  • Titan Pellets

    Pellet materials: glass-filled ABS and PC pellets produce strong and heat-resistant molds.

  • ProJet MJP 2500 MultiJet 3D Printer angle

    MJP Printers for fine-featured, complex thermoforming molds for thin sheet forming

  • visijet-m2s-ht250-dishwasher-arm

    Strong, rigid material with HDT up to 250C, ideal for high temperature tooling applications

  •

    Stereolithography (SLA) 3D  Printers for high-throughput, fine-feature, complex thermoforming molds with excellent surface quality for thin sheet forming

  • Imprimante Figure 4 Modular_angle

    Figure 4 3D Printers for  small, ultra-fast, fine-feature, complex thermoforming molds with excellent surface quality for thin sheet forming
